LOW TEMPERATURE VAPORIZED HYDROGEN PEROXIDE PLASMA STERILIZER CVM-100S

  • Commodity name: LOW TEMPERATURE VAPORIZED HYDROGEN PEROXIDE PLASMA STERILIZER CVM-100S

Key words:

Low-temp vaporized hydrogen peroxide plasma sterilization technology was patented in 1987 and launched in 1993 in USA.Plasma state is called as the 4th stage of matters by scientist following after the solid, liquid and gas in our universe.


Immediate consultation
+
  • undefined
  • undefined
  • undefined
  • undefined
  • undefined
  • undefined

Product Details


Sterilization principle:

Low-temp vaporized hydrogen peroxide plasma sterilization technology was patented in 1987 and launched in 1993 in USA.

Plasma state is called as the 4th stage of matters by scientist following after the solid, liquid and gas in our universe. The necessary condition to form plasma stage is by adapting the RF or microwave technology to generate into the charged particles which present as majority radical form in the extremely sealing vacuum container The radical is an atom with unpaired electrons, which can interact with enzymes and nucleic acid which is the essential cellular components to form into microorganism , in order to destroy the microorganism's metabolize, the high concentration of vaporized hydrogen peroxide after purification will diffusion into the chamber, at this time, combined with plasma to form a variety of free radicals like hydroxy and peroxyhydoxyls which can block the metabolize of microorganism, so as to achieve the purpose of sterilization. in the technology of low-temp vaporized hydrogen peroxide plasma sterilization, the plasma is not directly involved in the sterilization process, but can accelerate the decomposition of residue after sterilization process if apply the plasma technology into the vaporize hydrogen peroxide sterilization processing, which helps to reduce the exposure of harmful gases discharged after sterilization cycle and reduced the injury to hospitals nurses.

Main low-temp sterilization methods compare.

Sterilant Sterilization mechanism Temp(℃) Concentration
EO Alkylation 30-60 600-1200 mg/L
LTSF Alkylation 60-80 8-15 mg/L
VH₂ O₂ plasma Oxidize 40-50 6-10 mg/L
Peracetic acid Oxidize 50-55 0.20%

Applicablerange

>95%medicalinstrumentsandmaterialsareapplicableforlow-tempvaporizedhydrogenperoxideplasmasterlizationtechnologyincludingmajorityinstrumentsandmaterialwhichareavalableforhightempmoisturesteamsterilization.Vaporizedhydrogenperoxideplasmasterilizationtechnologyisespeciallyusedfortheinstrumentsandmaterialwhichcannotapplicableforhigh-tempmoisturesteamsterilizersuchasteflonPTFElumens,stainlesssteellumens,electroniclumens,othermentalalloymaterials,includ.ingbutnotlimitedtothefollowinginstruments:

Advantages



4 programs as standard configuration (e.g.CVM-120S-Total 150L)

Fast cycle (35mins) Standard cycle(45mins) Endo cycle(48mins) Drying cycle(20mins)

▶Flash surface sterilization for olidsurgical instruments or deviceswithout hollow lumens

▶Indicated engineer's maintenanceor service for the sterilizer

▶Mix loading

▶Solid instruments

▶Solid instruments

▶Super long lumens

▶Other devices which not applicablefor steam sterilizer and couldcompatible with re-processindmedical instruments

Note: this program cannot selectfor flexible endoscope's sterilization

▶Flexible endoscope

▶Flexible endoscope's tracking

Note: read the lFU of flexibleendoscope to define the correctsterilization method accordingly

▶Vacuum+hot air drying

Note: it is forced to initial underflexible endoscope program, andoptional under Fast cycle andStandard cycle

1 ampule 2 ampules 2 ampules
四川凯维茵科技有限公司 四川凯维茵科技有限公司 四川凯维茵科技有限公司 四川凯维茵科技有限公司

Sterilization effectiveness of half sterilization cycle

Material Type Diameter Length
Stainless steel lumen Through out 0.7mm 600mm
PTFE (Teflon) lumen Through out 1mm 4000mm

Multiple chamber sizes and models to meet with differenthospitals’requirements

Model Usable chambervolume Usable chambervolume Suggestion
CVM-60S 80L 60L

▶Veterinary, ophthalmology, dental clinic and laboratories

▶Surgery room of hospitals (reprocessing for emergency surgery,rapid turnover and short transit distance)

▶Limited room size of CSSD (single room)

CVM-100S 133L 108L

▶urgery room of hospitals (reprocessing for emergency surgery,rapid turnover and short transit distance)

▶CSSD of hospitals (single room)

CWM-120S;CVM-120D 150L 120L

▶Medium size CSSD of hospitals (single room)

▶Large size CSSD of hospital which need though out door project

CVM-150S:CVM-150D 186L 154L
CVM-200S-DUAL100 266L 200L

▶Small footprint, limited room size for low-temp sterilization solution

▶Surgical instruments quantity increased CSSD

▶CSSD which need to increase the turnover rate of surgicalinstruments rapidly

36672233-6453-4417-be2b-ba9534f00631 ecf4d98f-9334-41d2-86d5-41241cf0753b

Accessories and consumables

Installation dimensions (mm)

Specifications of CVM series Low-temp Vaporized H2O2 Plasma Sterilizer

Model CVM-100S
Door type Automatic sliding single door; safty protection
Installation method  Floor installation with movable caster
Chamber type Single chamber
Total chamber volume 133L
Usable chamber volume 106L
Chamber material Aircraft level aluminium
Chamber shape Rectangle
Power supply 3 Phases; 380V  50Hz
Programs (4 kinds) Fast:  35mins
Standard:  45mins
Flexi Endo: 48mins
Vacuum Drying: 20mins
Software function Humility detection
H2O2 concentration detection (optional)
Power display of plasma stage
Pressure display
Time display
Temp display
Input power ≤4200W;150L≤4800W
Constent temp power 1200W
Standby power About 25W
Noise ≤60dB
Operation environment temp 5℃~40℃
Operation environment humidity 30%~95%(No frosting)
Operation atmospheric 700hPa~1060hPa
Dosage volume of H2O2(ml) Testing:4mL/cycle Standard:8mL/cycle Flex endo:8mL/cycle
Cycle QNT/cassette Fast:12 cycles;   Standard:6 cycles; Flexi Endo: 6cycles
Chamber working temp 45℃~60℃
Maximum chamber vacuum degree <80Pa
Machine dimension(W*D*H) 820mm*1070mm*1790mm
Installation space(W*D*H) 1400mm*1500mm*2050mm
Instrument shelf Type: movable
Qantity and load capcity: 2 (4 available) shelves; total 30KG, 15kg/shelf
N.W. 440Kg
G.W. 500Kg
Panel material Q235 carbon steel with plastic spraying painting
Maintenance 6 months
Guarantee period 2 years
Touch screen 12inch; TFT true color; touch screen
Printer Internal needle printer
Data record and tracking Check and print at any time
Internet Of Things ( IOT) port opening with HIS/CSSD/CME/CSD system, USB port, RFID of endocope sterilization tracking
